6ms 4096×4096 42 Touch Screen Kiosk 3000/1LED Backlight

Product Categories
Shenzhen Smart Display Technology Co.,Ltd
Contact Now

6ms 4096×4096 42 Touch Screen Kiosk 3000/1LED Backlight

  • 1
  • 2

Model Number : ST-43

Certification : CE,FCC, ROHS ,CB

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T

Supply Ability : 3000

Delivery Time : 5-7days

Packaging Details : carton+ wooden box/flight case

Brand Name : Smart Display

Price : different price for different size

Life time : >60,000 hours

Brand : Smart Display

CPU : i3 i5 i7

Mainboard : H81

Customized service : yes

Contact Now

42inch interactive touch screen large touch screen kiosk white infrared touch screen kiosk

43 inch indoor LCD touch kiosk specification:

Panel type 43 inch LCD screen
DIsplay Area 941.18*529.41mm
Show ratio 16:9
Backlight LED backlight
Resolution 1920*1080
Color 16.7M (8bit)
Brightness 450 cd/m² optional
Contrast ratio 3000:1
Viewing Angle 178°(H) / 178°(V)
Response time 6ms
Life Expectancy 60000 hours

Touch Max Resolution 4096×4096
Transparency > 90%, Up to 100%
Scanning Speed >50Scans/S
Response Speed <12ms
Touch Type Horizontal Multi Dot Touch Screen (Vertical way is optional)
Touch precision 0.625mm
Minimum Touch object ≥5mm
Touch Intensity Over 60,000,000 Single Point Touch
Operation System DOS, WINDOWS9X/ME/2000/XP/2003/VISTA, LINUX
perating Voltage DC 5V ±5%
Power Supply Keyboard Serial Interface
Power <1W (Current<200mA)
Communication RS-232 Interface Port, USB Port
Vandal-Proof Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break
Temperature Operating -41°C ~70°C Temperature Storage: -50°C ~85°C
Altitude 3000m
Noise None
Life Time >10 Year

Infrared touchscreen Panel Parameters:


6ms 4096×4096 42 Touch Screen Kiosk 3000/1LED Backlight

6ms 4096×4096 42 Touch Screen Kiosk 3000/1LED Backlight

6ms 4096×4096 42 Touch Screen Kiosk 3000/1LED Backlight
